# From CSV to Reproducible ML Experiments: Building a Clean ML Pipeline with DVC + MLflow on DagsHub

Hiring managers want to see more than a Jupyter notebook — they want reproducibility, traceability, and the ability to collaborate at scale. This article shows a compact yet production-lean pipeline that checks those boxes using:

• DVC for data/model versioning and pipeline orchestration
• MLflow for experiment tracking and artifact logging
• scikit-learn for modeling (RandomForest)
• DagsHub as a remote hub for experiments and data

We go from raw CSV to a tracked, reproducible pipeline with hyperparameter search, metrics, and model artifacts — all wired to a remote tracking server.

What we’ll build

A simple ML pipeline on the Pima Indians Diabetes dataset (Outcome = 0/1), structured as:

params.yaml
README.md
requirements.txt

data/
  raw/
    data.csv
  processed/
    data.csv

src/
  preprocess.py
  train.py
  evaluate.py

models/
  model.pkl   # generated

Stages:

• Preprocess: read raw CSV → write cleaned/processed CSV
• Train: split, grid search a RandomForest, log metrics/artifacts to MLflow
• Evaluate: load the trained model and log evaluation metrics

This repo is DVC-ready and MLflow-enabled so you can rerun/compare experiments reliably and collaborate with others.

Tech stack

• Python 3.12 (works with 3.9+ as well)
• scikit-learn
• DVC (with optional remote storage)
• MLflow (remote tracking on DagsHub)

Install dependencies:

python -m venv .venv
source .venv/bin/activate
pip install -r requirements.txt

Parameters

`params.yaml` keeps configuration centralized and reproducible:

preprocess:
  input: data/raw/data.csv
  output: data/processed/data.csv

train:
  data: data/processed/data.csv
  model: models/model.pkl
  random_state: 42
  n_estimators: 100
  max_depth: 5

Stage 1 — Preprocess

A minimal preprocessing step that reads raw CSV and writes processed CSV. You can extend this to handle imputations, feature engineering, etc.

# src/preprocess.py
import pandas as pd
import yaml
import os

params = yaml.safe_load(open("params.yaml"))["preprocess"]

def preprocess(input_path, output_path):
    data = pd.read_csv(input_path)
    os.makedirs(os.path.dirname(output_path), exist_ok=True)
    data.to_csv(output_path)
    print(f"Preprocessed data saved to {output_path}")

if __name__ == "__main__":
    preprocess(params["input"], params["output"])

Run it:

python src/preprocess.py

With DVC you can also declare this as a stage and make it fully reproducible with dependency tracking (see the DVC section below).

Stage 2 — Train with hyperparameter search and MLflow tracking

Key ideas:

• Reproducible train/test split
• GridSearchCV over a RandomForest
• Logging metrics, params, confusion matrix, classification report
• Saving the model locally (pickle)
• Logging the model file to MLflow as an artifact (compatible with DagsHub)

Tip for credentials (don’t hardcode secrets):

export MLFLOW_TRACKING_URI="https://dagshub.com/<user>/<repo>.mlflow"
export MLFLOW_TRACKING_USERNAME="<your_username>"
export MLFLOW_TRACKING_PASSWORD="<your_token>"

On typical runs, accuracy is often around ~0.75–0.80 (varies by split). You can inspect full metrics and artifacts in the MLflow UI.

Stage 3 — Evaluate

Load the saved model and compute evaluation metrics across the processed dataset; log the evaluation accuracy to MLflow.

# src/evaluate.py (core excerpts)
import pandas as pd
import pickle
from sklearn.metrics import accuracy_score
import yaml
import os
import mlflow

params = yaml.safe_load(open("params.yaml"))["train"]

def evaluate(data_path, model_path):
    data = pd.read_csv(data_path)
    X = data.drop(columns=["Outcome"])
    y = data["Outcome"]

    mlflow.set_tracking_uri(os.environ["MLFLOW_TRACKING_URI"])

    with open(model_path, "rb") as f:
        model = pickle.load(f)

    y_pred = model.predict(X)
    accuracy = accuracy_score(y, y_pred)
    mlflow.log_metric("evaluation_accuracy", accuracy)
    print(f"Evaluation Accuracy: {accuracy}")

if __name__ == "__main__":
    evaluate(params["data"], params["model"])

Running locally

1) Prepare environment and install deps

2) Configure MLflow tracking to DagsHub

3) Run the stages directly:

python src/preprocess.py
python src/train.py
python src/evaluate.py

Optional: DVC stages for full reproducibility

Declare the workflow as DVC stages:

dvc stage add -n preprocess \
  -p preprocess.input,preprocess.output \
  -d src/preprocess.py -d data/raw/data.csv \
  -o data/processed/data.csv \
  python src/preprocess.py

dvc stage add -n train \
  -p train.data,train.model,train.random_state,train.n_estimators,train.max_depth \
  -d src/train.py -d data/raw/data.csv \
  -o models/model.pkl \
  python src/train.py

dvc stage add -n evaluate \
  -d src/evaluate.py -d models/model.pkl -d data/raw/data.csv \
  python src/evaluate.py

Then:

dvc repro  # re-run pipeline when data/code/params change

You can push large files (data, models) to a DVC remote (S3, DagsHub, etc.) and keep the git repo light.

A common gotcha: MLflow Model Registry endpoints on DagsHub

On some hosted MLflow endpoints (including DagsHub), Model Registry APIs may not be supported. If you try:

mlflow.sklearn.log_model(best_model, "model", registered_model_name="Best Model")

…you may see an error mentioning an unsupported endpoint. The safe alternative is to save and upload your model as a plain artifact:

pickle.dump(best_model, open(model_path, "wb"))
mlflow.log_artifact(model_path, artifact_path="model")

This keeps your model versioned within the run while avoiding registry-specific APIs.

Why this project is hiring-manager friendly

• Reproducibility by design: params.yaml, DVC stages, pinned requirements
• Observability: MLflow logs metrics, params, and artifacts for every run
• Good engineering practices: isolated environment, clear structure
• Practical MLOps exposure: remote experiment tracking (DagsHub) and pipeline orchestration (DVC)

What I’d build next

• Add unit tests for data and model contracts (e.g., column schemas, shapes)
• Add CI to validate pipeline stages and run a smoke experiment on PRs
• Package model for inference (FastAPI + Docker) and deploy a small endpoint
• Add feature engineering and proper train/validation/test splits
• Switch to MLflow pyfunc format when using a registry-capable server

Wrap-up

You now have a reproducible, remotely tracked ML pipeline that’s easy to demo and extend. Fork it, tweak the model/params, and compare runs like a pro.
