From Zero to MLflow: Tracking, Tuning, and Deploying a Keras Model (Hands-on)

# From Zero to MLflow: Tracking, Tuning, and Deploying a Keras Model (Hands-on)

I practiced MLflow end to end across two notebook folders (`1-MLproject` and `2-DLproject`) to learn how to track experiments, compare runs, pick the best model, and serve it. This post distills the workflow with runnable snippets.

What you’ll build

• Run and track training experiments with MLflow
• Log parameters, metrics, and models from Keras/TensorFlow
• Tune hyperparameters with Hyperopt and compare runs in the MLflow UI
• Pick the best run, register a model, and serve it via a local REST API

Repo layout used:

• `1-MLproject/` — classic ML experimentation (e.g., house price notebook)
• `2-DLproject/` — deep learning quickstart with MLflow tracking + Hyperopt
• `requirements.txt` — dependencies to reproduce runs

Environment and data

Install dependencies and (optionally) start the UI:

pip install -r requirements.txt
mlflow ui --port 5000

Dataset: White wine quality from the MLflow repo.

import pandas as pd

data = pd.read_csv(
    "https://raw.githubusercontent.com/mlflow/mlflow/master/tests/datasets/winequality-white.csv",
    sep=";",
)

Train/valid/test split:

from sklearn.model_selection import train_test_split

train, test = train_test_split(data, test_size=0.25, random_state=42)

train_x = train.drop(["quality"], axis=1).values
train_y = train[["quality"]].values.ravel()

test_x = test.drop(["quality"], axis=1).values
test_y = test["quality"].values.ravel()

train_x, valid_x, train_y, valid_y = train_test_split(
    train_x, train_y, test_size=0.20, random_state=42
)

Infer a model signature for safer serving later:

import mlflow
from mlflow.models import infer_signature

signature = infer_signature(train_x, train_y)

Set up MLflow experiment

import mlflow

mlflow.set_experiment("/wine-quality")

This creates/uses the “wine-quality” experiment namespace so your runs are grouped in the UI.

A simple Keras model with MLflow logging

The training function below trains a small network and logs params, metrics, and the model to MLflow.

Each hyperparameter trial is recorded as a nested MLflow run.

import numpy as np
import keras
import mlflow
from hyperopt import STATUS_OK


def train_model(params, epochs, train_x, train_y, valid_x, valid_y):
    mean = np.mean(train_x, axis=0)
    var = np.var(train_x, axis=0)

    model = keras.Sequential([
        keras.Input([train_x.shape[1]]),
        keras.layers.Normalization(mean=mean, variance=var),
        keras.layers.Dense(64, activation="relu"),
        keras.layers.Dense(1),
    ])

    model.compile(
        optimizer=keras.optimizers.SGD(
            learning_rate=params["lr"],
            momentum=params["momentum"],
        ),
        loss="mean_squared_error",
        metrics=[keras.metrics.RootMeanSquaredError()],
    )

    with mlflow.start_run(nested=True):
        model.fit(
            train_x,
            train_y,
            validation_data=(valid_x, valid_y),
            epochs=epochs,
            batch_size=64,
            verbose=0,
        )

        _, eval_rmse = model.evaluate(valid_x, valid_y, batch_size=64, verbose=0)

        mlflow.log_params(params)
        mlflow.log_metric("eval_rmse", float(eval_rmse))

        mlflow.tensorflow.log_model(model, "model", signature=signature)

        return {"loss": float(eval_rmse), "status": STATUS_OK, "model": model}

Hyperparameter tuning with Hyperopt (and MLflow tracking)

Define the search space and objective:

from hyperopt import fmin, tpe, hp, Trials

space = {
    "lr": hp.loguniform("lr", np.log(1e-5), np.log(1e-1)),
    # Momentum is in [0, 1] so use uniform (not loguniform)
    "momentum": hp.uniform("momentum", 0.0, 1.0),
}


def objective(params):
    return train_model(
        params=params,
        epochs=3,
        train_x=train_x,
        train_y=train_y,
        valid_x=valid_x,
        valid_y=valid_y,
    )

Run the sweep under a parent run so it’s easy to register later:

import mlflow

mlflow.set_experiment("/wine-quality")

with mlflow.start_run() as parent_run:
    trials = Trials()

    best_params = fmin(
        fn=objective,
        space=space,
        algo=tpe.suggest,
        max_evals=4,
        trials=trials,
        rstate=np.random.default_rng(42),
    )

    best_trial = sorted(trials.results, key=lambda x: x["loss"])[0]

    mlflow.log_params(best_params)
    mlflow.log_metric("eval_rmse", best_trial["loss"])
    mlflow.tensorflow.log_model(best_trial["model"], "model", signature=signature)

    parent_run_id = parent_run.info.run_id

print("Best parameters:", best_params)
print("Best eval RMSE:", best_trial["loss"])
print("Parent run:", parent_run_id)

Open the MLflow UI at `http://127.0.0.1:5000` to compare runs and metrics under the “wine-quality” experiment.

Register the winner in the Model Registry

Register the parent run’s model artifact:

from mlflow import register_model

result = register_model(
    model_uri=f"runs:/{parent_run_id}/model",
    name="finalmodel",
)

print("Registered model:", result.name, "version:", result.version)

This produces a registry entry like `models:/finalmodel/1`.

Serve the model as a REST API

Serve a specific version from the registry:

mlflow models serve -m "models:/finalmodel/1" -p 5001 --no-conda

Send a sample request (wine dataset has 11 numeric features):

curl -s http://127.0.0.1:5001/invocations \
  -H 'Content-Type: application/json' \
  -d '{"instances": [[7.0, 0.27, 0.36, 20.7, 0.045, 45.0, 170.0, 1.0010, 3.00, 0.45, 8.8]]}'

You can also serve directly from a run:

mlflow models serve -m "runs:/$RUN_ID/model" -p 5001 --no-conda

Comparing with a classic ML notebook (house prices)

The same tracking pattern works for classic ML:

import mlflow

mlflow.set_experiment("/house-prices")

with mlflow.start_run():
    mlflow.log_params({"model": "RandomForest", "n_estimators": 200})
    mlflow.log_metric("rmse", 0.123)
    mlflow.sklearn.log_model(model, "model")

Troubleshooting and gotchas

• Hyperopt distributions: `hp.loguniform` samples `exp(U(low, high))` so `low`/`high` must be logs of positive numbers. For [0, 1] ranges (like momentum), use `hp.uniform`.
• Nested runs: use `mlflow.start_run(nested=True)` for each trial so the UI keeps the tree under a single parent sweep.
• Signatures: `infer_signature` helps validation at serving time and documents expected input/outputs.
• Reproducibility: fix random seeds and log data/code versions (e.g., git commit hash tags).
• UI hiccups: refresh and confirm you’re in the right experiment.

What I’d improve next

• Use `mlflow.autolog()` to capture more metrics automatically
• Add explicit data lineage (feature store / data versioning)
• Wire CI to run selected experiments and auto-register on metric thresholds
• Use Docker for consistent serving environments

Try it yourself

1) Install and run the sweep (end-to-end script)

2) Start the UI: `mlflow ui --port 5000`

3) Serve your registered model: `mlflow models serve -m "models:/finalmodel/1" -p 5001 --no-conda`

That’s it — you now have a repeatable workflow for tracking, selecting, and serving models with MLflow.
